Static weighing conveyor specifications:
| MODEL | ITCW-S-30 | ITCW-S-50 | ITCW-S-100 |
| Weighing weight (kg) | 0.1-30 kg | 0.1-50 kg | 0.1-100 kg |
| Jump step (g) | 5 g | 10 g | 10 g |
| Weighing accuracy (g) | ± 10 g | ± 20 g | ± 30 g |
| IP stacking | IP67 | IP67 | IP67 |
| Conveyor speed (m / phút) | 15 | 15 | 15 |
| Production (Sp/ giờ) | Up to 1000 | Up to 1000 | Up to 1000 |
| Product size (L*W mm) | 1000x600 | 1000x600 | 1000x600 |
| Height (mm) | 500~ 1000 mm | ||
| Options | Network interface, Ethernet, data output, signal feedback | ||
| Voltage | 1P- 220V/3P- 380V AC ± 10% 50 Hz |
Application of static weighing conveyor:
- Used to check the weight of packaged products in the production line & widely used in industries: food production, pharmaceuticals, chemicals, logistics centers...
- The product is suitable for lines with low output and low initial investment costs.
- The weight of the object will be measured by the force sensor and transmitted to the weighing indicator, then compared with the specified weight to give the result of whether the product meets the net weight requirements or not.
